Gamme BienTempéréeThéorique
  Game Bien Tempérée Théorique (GBTT)
      Diapason: La 440.0 Hz
 Note la plus grave 1ère octave 2ème octave 3ème octave 4ème octave 5ème octave 6ème octave 7ème octave 8ème octave 9ème octave
 LA 27.5 55.00000000000002 110.00000000000006 220.00000000000026 440.0 880.0000000000003 1760.000000000001 3520.000000000004 7040.000000000013 14080.000000000033
 Sib=La# 29.13523509488062 58.27047018976126 116.54094037952254 233.08188075904525 466.1637615180899 932.3275230361802 1864.6550460723606 3729.310092144724 7458.6201842894525 14917.240368578912
 SI 30.867706328507758 61.73541265701554 123.4708253140311 246.94165062806238 493.8833012561241 987.7666025122486 1975.5332050244976 3951.066410048998 7902.132820098001 15804.265640196008
 DO 32.703195662574835 65.40639132514968 130.8127826502994 261.62556530059896 523.2511306011974 1046.502261202395 2093.0045224047904 4186.009044809583 8372.018089619172 16744.036179238352
 DO#=Réb 34.64782887210902 69.29565774421805 138.59131548843615 277.1826309768725 554.3652619537443 1108.7305239074888 2217.4610478149784 4434.92209562996 8869.844191259925 17739.688382519857
 RE 36.708095989675954 73.41619197935192 146.8323839587039 293.66476791740797 587.3295358348153 1174.6590716696307 2349.3181433392624 4698.6362866785275 9397.27257335706 18794.54514671413
 Mib=Ré# 38.89087296526012 77.78174593052026 155.5634918610406 311.1269837220814 622.253967444162 1244.5079348883241 2489.0158697766497 4978.031739553302 9956.06347910661 19912.126958213226
 MI 41.203444614108754 82.40688922821752 164.81377845643513 329.62755691287043 659.2551138257401 1318.5102276514804 2637.020455302962 5274.040910605927 10548.08182121186
 FA 43.6535289291255 87.30705785825101 174.6141157165021 349.22823143300445 698.456462866008 1396.9129257320162 2793.825851464034 5587.651702928071 11175.303405856148
 FA#=solb 46.249302838954314 92.49860567790864 184.9972113558174 369.994422711635 739.988845423269 1479.9776908465383 2959.9553816930784 5919.91076338616 11839.821526772326
 SOL 48.99942949771868 97.99885899543737 195.99771799087486 391.99543598174995 783.9908719634989 1567.981743926998 3135.963487853998 6271.926975707999 12543.853951416006
 SOL#=Lab 51.91308719749316 103.82617439498634 207.6523487899728 415.30469757994587 830.6093951598906 1661.2187903197814 3322.4375806395647 6644.875161279134 13289.750322558275
 Aux arrondis près  ce tableau est strictement confome à la gamme bien tempérée théorique  chère à Jean Sébastien Bach.
 Les demi-tons y sont absoluments égaux et sont obtenus à partir du choix d'un diapason qui peut être ajusté à la valeur souhaitée.
 La valeur habituelle est le La 440 Hz
 A titre d'exemple  l'accordage classique d'une guitare 6 cordes est:
 Mi 1ère octave  82.41 Hz
 La 2ème octave  110.0 Hz
 Ré 2ème octave  146.83 Hz
 Sol 2ème octave  196.0 Hz
 Si 3ème octave  246.94 Hz
 Mi 3ème octave  329.63 Hz
 Celui d'une basse électrique 4 cordes:
 Mi grave  41.2 Hz
 La 1ère octave  55.0 Hz
 Ré 1ère octave  73.42 Hz
 Sol  1ère octave  98.0 Hz
Universal Guitar Stings Gauges
 Strictement valable pour les cordes d'Addario  extrapolable aux autres marques
 (source: http://www.daddariostrings.com/img/Tension_chart.pdf)
  Utilisation
 1) renseigner fréquence et longueur  les autres valeurs sont calculées
 2) choisir une tension en livre (lb)
 3) pour chaque note à vide  trouver la corde dont la tension est la plus proche de la tension choisie
 La masse linéique (Unit Weight) est indiquée en livre-masse par pouce (lb/in)
 Fréquence (Hz):   261.63  (fréquence  en Hertz  de la note à vide choisie)
 Longueur (pouces):   25.5  (longeur  en pouces  de la corde à vide)
 Plain Steel        Exemples d'accordages
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)   Accordage classique d'une guitare 6 cordes
 PL007 0.007 " 1.085e-05 lb/in 4.999286833427446 lb  Mi 1ère octave 82.41 Hz
 PL008 0.008 " 1.418e-05 lb/in 6.533630165714394 lb  La 2ème octave 110.0 Hz
 PL0085 0.085 " 1.6e-05 lb/in 7.372220215192546 lb  Ré 2ème octave 146.83 Hz
 PL009 0.09 " 1.794e-05 lb/in 8.266101916284644 lb  Sol 2ème octave 196.0 Hz
 PL0095 0.085 " 1.999e-05 lb/in 9.210667631356186 lb  Si 3ème octave 246.94 Hz
 PL010 0.01 " 2.215e-05 lb/in 10.205917360407181 lb  Mi 3ème octave 329.63 Hz
 PL0105 0.0105 " 2.44e-05 lb/in 11.242635828168634 lb  Accordage classique d'une basse 4 cordes
 PL011 0.011 " 2.68e-05 lb/in 12.348468860447515 lb  Mi octave grave 41.2 Hz
 PL0115 0.0115 " 2.93e-05 lb/in 13.500378269071353 lb  La octave grave 55.0 Hz
 PL012 0.012 " 3.19e-05 lb/in 14.698364054040141 lb  Ré octave grave 73.42 Hz
 PL013 0.013 " 3.744e-05 lb/in 17.25099530355056 lb  Sol octave grrave 98.0 Hz
 PL014 0.014 " 4.3422e-05 lb/in 20.007284136505675 lb
 PL015 0.015 " 4.9842e-05 lb/in 22.965387497851683 lb
 PL016 0.016 " 5.6713e-05 lb/in 26.13129531651343 lb
 PL017 0.017 " 6.4023e-05 lb/in 29.499478427329525 lb
 PL018 0.018 " 7.1772e-05 lb/in 33.069936830299966 lb
 PL019 0.019 " 7.9973e-05 lb/in 36.8486604543496 lb
 PL020 0.02 " 8.8613e-05 lb/in 40.82965937055357 lb
 PL022 0.022 " 0.000107223 lb/in 49.404473008349406 lb
 PL024 0.024 " 0.000127604 lb/in 58.795299271214354 lb
 PL026 0.026 " 0.000149754 lb/in 69.00121663162153 lb
 Nickelplated Steel Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 NW017 0.017 " 5.524e-05 lb/in 25.452590292952266 lb
 NW018 0.018 " 6.215e-05 lb/in 28.636467898388556 lb
 NW019 0.019 " 6.947e-05 lb/in 32.009258646839136 lb
 NW020 0.02 " 7.495e-05 lb/in 34.534244070542584 lb
 NW021 0.021 " 8.293e-05 lb/in 38.21113890286986 lb
 NW022 0.022 " 9.184e-05 lb/in 42.31654403520521 lb
 NW024 0.024 " 0.00010857 lb/in 50.025121797715926 lb
 NW026 0.026 " 0.00012671 lb/in 58.38337646669048 lb
 NW028 0.028 " 0.00014666 lb/in 67.57561354750868 lb
 NW030 0.03 " 0.00017236 lb/in 79.41724226816171 lb
 NW032 0.032 " 0.00019347 lb/in 89.14396531458138 lb
 NW034 0.034 " 0.0002159 lb/in 99.47889652875443 lb
 NW036 0.036 " 0.00023964 lb/in 110.41742827304637 lb
 NW038 0.038 " 0.00026471 lb/in 121.96877582272619 lb
 NW039 0.04 " 0.00027932 lb/in 128.7005344067239 lb
 NW042 0.042 " 0.00032279 lb/in 148.72993520387516 lb
 NW044 0.044 " 0.00035182 lb/in 162.1059072568151 lb
 NW046 0.046 " 0.00038216 lb/in 176.08547983987395 lb
 NW048 0.048 " 0.00041382 lb/in 190.67326059068625 lb
 NW049 0.049 " 0.00043014 lb/in 198.1929252101826 lb
 NW052 0.052 " 0.00048109 lb/in 221.6688389579364 lb
 NW054 0.054 " 0.00053838 lb/in 248.0659949659602 lb
 NW056 0.056 " 0.00057598 lb/in 265.3907124716627 lb
 NW059 0.059 " 0.00064191 lb/in 295.7688673958905 lb
 NW060 0.06 " 0.00066542 lb/in 306.601423474589 lb
 NW062 0.062 " 0.00070697 lb/in 325.74615784591714 lb
 NW064 0.064 " 0.00074984 lb/in 345.49910038499877 lb
 NW066 0.066 " 0.00079889 lb/in 368.0995629821984 lb
 NW068 0.068 " 0.00084614 lb/in 389.8706508051888 lb
 NW070 0.07 " 0.00089304 lb/in 411.480471310972 lb
 NW072 0.072 " 0.00094124 lb/in 433.6892847092396 lb
 NW074 0.074 " 0.00098869 lb/in 455.55252528491997 lb
 NW080 0.08 " 0.00115011 lb/in 529.9290119809438 lb
 Stainless Steel Rounwound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 XSG028 0.028 " 0.00015493 lb/in 71.38612987123634 lb
 XSG030 0.03 " 0.00018203 lb/in 83.8728278607187 lb
 XSG032 0.032 " 0.00020398 lb/in 93.98659246843599 lb
 XSG034 0.034 " 0.00022729 lb/in 104.72699579444462 lb
 XSG036 0.036 " 0.00025198 lb/in 116.10325311401363 lb
 XSG038 0.038 " 0.00027804 lb/in 128.11075678950849 lb
 XSG040 0.04 " 0.00031044 lb/in 143.03950272527337 lb
 XSG042 0.042 " 0.00033924 lb/in 156.30949911261996 lb
 XSG046 0.046 " 0.00040096 lb/in 184.74783859272526 lb
 XSG048 0.048 " 0.00043387 lb/in 199.91157404784937 lb
 XSG050 0.05 " 0.00046816 lb/in 215.7111634965339 lb
 XSG052 0.052 " 0.00050382 lb/in 232.14199930114432 lb
 XSG054 0.054 " 0.00056388 lb/in 259.81547093392334 lb
 XSG056 0.056 " 0.00060297 lb/in 277.8267264471656 lb
 XSG070 0.07 " 0.00092592 lb/in 426.63038385319265 lb
 Stainless Steel Half Round
 Item# Tirant (pouces)  Unit Weight (lb/in)  Tension (livres)
 HRG022 0.022 " 0.00011271 lb/in 51.93268377839699 lb
 HRG024 0.024 " 0.00012857 lb/in 59.24039706670661 lb
 HRG026 0.026 " 0.0001475 lb/in 67.9626551088063 lb
 HRG030 0.03 " 0.0001897 lb/in 87.40688592637663 lb
 HRG032 0.032 " 0.000211 lb/in 97.22115408785172 lb
 HRG036 0.036 " 0.0002565 lb/in 118.1859053248055 lb
 HRG039 0.039 " 0.000297 lb/in 136.84683774451167 lb
 HRG042 0.042 " 0.000334 lb/in 153.8950969921444 lb
 HRG046 0.046 " 0.0003981 lb/in 183.43005422925955 lb
 HRG052 0.052 " 0.000495 lb/in 228.07806290751938 lb
 HRG056 0.056 " 0.000567 lb/in 261.2530538758859 lb
 Chromes - Stainless Steel Flat Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 CG020 0.02 " 7.812e-05 lb/in 35.994865200677616 lb
 CG022 0.022 " 9.784e-05 lb/in 45.08112661590242 lb
 CG024 0.022 " 0.00011601 lb/in 53.45320419778046 lb
 CG026 0.022 " 0.00013574 lb/in 62.54407325063977 lb
 CG028 0.022 " 0.00014683 lb/in 67.6539433872951 lb
 CG030 0.022 " 0.00016958 lb/in 78.13631900577201 lb
 CG032 0.022 " 0.00019233 lb/in 88.6186946242489 lb
 CG035 0.035 " 0.00024197 lb/in 111.49100784188377 lb
 CG038 0.036 " 0.0002652 lb/in 122.19455006681648 lb
 CG040 0.04 " 0.00031676 lb/in 145.95152971027443 lb
 CG042 0.042 " 0.00034377 lb/in 158.39675896104637 lb
 CG045 0.045 " 0.00040393 lb/in 186.1163069701703 lb
 CG048 0.048 " 0.00043541 lb/in 200.6211502435617 lb
 CG050 0.05 " 0.00047042 lb/in 216.75248960192988 lb
 CG052 0.052 " 0.00049667 lb/in 228.84753839248017 lb
 CG056 0.056 " 0.00059075 lb/in 272.19619325781235 lb
 CG065 0.065 " 0.00089364 lb/in 411.75692956904174 lb
 Phosphor Bronze - Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 PB020 0.02 " 8.106e-05 lb/in 37.34951066521924 lb
 PB021 0.021 " 8.944e-05 lb/in 41.21071100292634 lb
 PB022 0.022 " 9.876e-05 lb/in 45.50502927827599 lb
 PB023 0.023 " 0.00010801 lb/in 49.76709409018419 lb
 PB024 0.024 " 0.00011682 lb/in 53.82642284617458 lb
 PB025 0.025 " 0.00012686 lb/in 58.45249103120789 lb
 PB026 0.026 " 0.0001364 lb/in 62.848177334516464 lb
 PB027 0.027 " 0.00014834 lb/in 68.3496966701039 lb
 PB029 0.029 " 0.00017381 lb/in 80.08534972516354 lb
 PB030 0.03 " 0.0001866 lb/in 85.9785182596831 lb
 PB032 0.032 " 0.00021018 lb/in 96.84332780182308 lb
 PB034 0.034 " 0.00023887 lb/in 110.06264017519023 lb
 PB035 0.035 " 0.00025365 lb/in 116.87272859897435 lb
 PB036 0.036 " 0.0002683 lb/in 123.62291773351001 lb
 PB039 0.039 " 0.00031125 lb/in 143.4127213736675 lb
 PB042 0.042 " 0.00036722 lb/in 169.20166921393795 lb
 PB045 0.045 " 0.00041751 lb/in 192.373478877815 lb
 PB047 0.047 " 0.00045289 lb/in 208.67530082865952 lb
 PB049 0.049 " 0.00049151 lb/in 226.46999737308056 lb
 PB052 0.052 " 0.00055223 lb/in 254.44757308973627 lb
 PB053 0.053 " 0.00056962 lb/in 262.4602549361236 lb
 PB056D 0.056 " 0.00063477 lb/in 292.4790141248608 lb
 PB059 0.059 " 0.00070535 lb/in 324.99972054912894 lb
 PB060 0.06 " 0.00073039 lb/in 336.53724518590525 lb
 PB062 0.062 " 0.00077682 lb/in 357.93050672286716 lb
 PB064 0.064 " 0.0008278 lb/in 381.4202433835244 lb
 PB066 0.066 " 0.00087718 lb/in 404.1727580226624 lb
 PB070 0.07 " 0.00096833 lb/in 446.1713750610874 lb
 Copyright Jean-Pierre "lbop" Bourgeois 2002
M11 (E) 82 41 Hz
 1 ère corde    Mi (E)1ère octave     82.41 Hz
 Strictement valable pour les cordes d'Addario  extrapolable aux autres marques
 (source: http://www.daddariostrings.com/img/Tension_chart.pdf)
 Fréquence (Hz):   82.41 Hz (fréquence  en Hertz  de la note à vide choisie)
  Utilisation
 1) renseigner la longueur  les autres valeurs sont calculées
 2) choisir une tension en livre (lb)
 La masse linéique (Unit Weiht) est indiquée en livre-masse par pouce (lb/in)
 Longueur (pouces):   25.5  (longeur  en pouces  de la corde à vide)
 Plain Steel
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)   A titre d'exemple  l'accordage classique d'une guitare 6 cordes est:
 PL007 0.007 " 1.085e-05 lb/in 0.4960127051730978 lb
 PL008 0.008 " 1.418e-05 lb/in 0.6482451759773757 lb  n° de corde note fréquence
 PL0085 0.085 " 1.6e-05 lb/in 0.7314473071677019 lb  1.0 Mi (E)1ère octave 82.41 Hz
 PL009 0.09 " 1.794e-05 lb/in 0.8201352931617858 lb  2.0 La (A) 2ème octave 110.0 Hz
 PL0095 0.085 " 1.999e-05 lb/in 0.9138519793926475 lb  3.0 Ré (D) 2ème octave 146.83 Hz
 PL010 0.01 " 2.215e-05 lb/in 1.0125973658602871 lb  4.0 Sol (G) 2ème octave 196.0 Hz
 PL0105 0.0105 " 2.44e-05 lb/in 1.1154571434307454 lb  5.0 Si (B) 3ème octave 264.94 Hz
 PL011 0.011 " 2.68e-05 lb/in 1.2251742395059004 lb  6.0 Mi (E) 3ème octave 329.63 Hz
 PL0115 0.0115 " 2.93e-05 lb/in 1.339462881250854 lb
 PL012 0.012 " 3.19e-05 lb/in 1.458323068665606 lb
 PL013 0.013 " 3.744e-05 lb/in 1.7115866987724222 lb
 PL014 0.014 " 4.3422e-05 lb/in 1.9850565607397468 lb
 PL015 0.015 " 4.9842e-05 lb/in 2.278549792740787 lb
 PL016 0.016 " 5.6713e-05 lb/in 2.5926606957126173 lb
 PL017 0.017 " 6.4023e-05 lb/in 2.9268406841748607 lb
 PL018 0.018 " 7.1772e-05 lb/in 3.2810897581275182 lb
 PL019 0.019 " 7.9973e-05 lb/in 3.6560022185076644 lb
 PL020 0.02 " 8.8613e-05 lb/in 4.0509837643782225 lb
 PL022 0.022 " 0.000107223 lb/in 4.901748413527655 lb
 PL024 0.024 " 0.000127604 lb/in 5.833475136489215 lb
 PL026 0.026 " 0.000149754 lb/in 6.846072502349501 lb
 Nickelplated Steel Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 NW017 0.017 " 5.524e-05 lb/in 2.5253218279964904 lb
 NW018 0.018 " 6.215e-05 lb/in 2.8412156337795422 lb
 NW019 0.019 " 6.947e-05 lb/in 3.175852776808765 lb
 NW020 0.02 " 7.495e-05 lb/in 3.4263734795137037 lb
 NW021 0.021 " 8.293e-05 lb/in 3.7911828239635947 lb
 NW022 0.022 " 9.184e-05 lb/in 4.198507543142608 lb
 NW024 0.024 " 0.00010857 lb/in 4.963327133699837 lb
 NW026 0.026 " 0.00012671 lb/in 5.792605518201219 lb
 NW028 0.028 " 0.00014666 lb/in 6.704628879325948 lb
 NW030 0.03 " 0.00017236 lb/in 7.8795161164640675 lb
 NW032 0.032 " 0.00019347 lb/in 8.844569407358454 lb
 NW034 0.034 " 0.0002159 lb/in 9.869967101094176 lb
 NW036 0.036 " 0.00023964 lb/in 10.955252043104256 lb
 NW038 0.038 " 0.00026471 lb/in 12.101338542522646 lb
 NW039 0.04 " 0.00027932 lb/in 12.769241364880154 lb
 NW042 0.042 " 0.00032279 lb/in 14.756492267541404 lb
 NW044 0.044 " 0.00035182 lb/in 16.083611975483805 lb
 NW046 0.046 " 0.00038216 lb/in 17.47061893170056 lb
 NW048 0.048 " 0.00041382 lb/in 18.917970290758646 lb
 NW049 0.049 " 0.00043014 lb/in 19.664046544069706 lb
 NW052 0.052 " 0.00048109 lb/in 21.993249062831847 lb
 NW054 0.054 " 0.00053838 lb/in 24.612287577059206 lb
 NW056 0.056 " 0.00057598 lb/in 26.33118874890331 lb
 NW059 0.059 " 0.00064191 lb/in 29.345208809001218 lb
 NW060 0.06 " 0.00066542 lb/in 30.41997919597076 lb
 NW062 0.062 " 0.00070697 lb/in 32.31945642177188 lb
 NW064 0.064 " 0.00074984 lb/in 34.27927805041435 lb
 NW066 0.066 " 0.00079889 lb/in 36.52162120145034 lb
 NW068 0.068 " 0.00084614 lb/in 38.68167653042995 lb
 NW070 0.07 " 0.00089304 lb/in 40.825731449565275 lb
 NW072 0.072 " 0.00094124 lb/in 43.02921646240798 lb
 NW074 0.074 " 0.00098869 lb/in 45.19841488272719 lb
 NW080 0.08 " 0.00115011 lb/in 52.57780390291534 lb
 Stainless Steel Rounwound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 XSG028 0.028 " 0.00015493 lb/in 7.082695706218253 lb
 XSG030 0.03 " 0.00018203 lb/in 8.321584582733548 lb
 XSG032 0.032 " 0.00020398 lb/in 9.32503885725424 lb
 XSG034 0.034 " 0.00022729 lb/in 10.390666152884185 lb
 XSG036 0.036 " 0.00025198 lb/in 11.519380778757345 lb
 XSG038 0.038 " 0.00027804 lb/in 12.710725580306741 lb
 XSG040 0.04 " 0.00031044 lb/in 14.191906377321333 lb
 XSG042 0.042 " 0.00033924 lb/in 15.508511530223197 lb
 XSG046 0.046 " 0.00040096 lb/in 18.330069517622608 lb
 XSG048 0.048 " 0.00043387 lb/in 19.834565197553175 lb
 XSG050 0.05 " 0.00046816 lb/in 21.402148207726956 lb
 XSG052 0.052 " 0.00050382 lb/in 23.032361393576966 lb
 XSG054 0.054 " 0.00056388 lb/in 25.77803172285773 lb
 XSG056 0.056 " 0.00060297 lb/in 27.565048925181824 lb
 XSG070 0.07 " 0.00092592 lb/in 42.328855665794904 lb
 Stainless Steel Half Round
 Item# Tirant (pouces)  Unit Weight (lb/in)  Tension (livres)
 HRG022 0.022 " 0.00011271 lb/in 5.152589124429479 lb
 HRG024 0.024 " 0.00012857 lb/in 5.877636267659465 lb
 HRG026 0.026 " 0.0001475 lb/in 6.743029862952253 lb
 HRG030 0.03 " 0.0001897 lb/in 8.672222135607065 lb
 HRG032 0.032 " 0.000211 lb/in 9.645961363274068 lb
 HRG036 0.036 " 0.0002565 lb/in 11.72601464303222 lb
 HRG039 0.039 " 0.000297 lb/in 13.577490639300466 lb
 HRG042 0.042 " 0.000334 lb/in 15.268962537125777 lb
 HRG046 0.046 " 0.0003981 lb/in 18.19932331146638 lb
 HRG052 0.052 " 0.000495 lb/in 22.62915106550078 lb
 HRG056 0.056 " 0.000567 lb/in 25.920663947755436 lb
 Chromes - Stainless Steel Flat Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 CG020 0.02 " 7.812e-05 lb/in 3.5712914772463042 lb
 CG022 0.022 " 9.784e-05 lb/in 4.472800283330496 lb
 CG024 0.022 " 0.00011601 lb/in 5.303450131532819 lb
 CG026 0.022 " 0.00013574 lb/in 6.205416092183991 lb
 CG028 0.022 " 0.00014683 lb/in 6.712400506964604 lb
 CG030 0.022 " 0.00016958 lb/in 7.752427146843681 lb
 CG032 0.022 " 0.00019233 lb/in 8.792453786722756 lb
 CG035 0.035 " 0.00024197 lb/in 11.061769057210551 lb
 CG038 0.036 " 0.0002652 lb/in 12.123739116304657 lb
 CG040 0.04 " 0.00031676 lb/in 14.480828063652579 lb
 CG042 0.042 " 0.00034377 lb/in 15.715602549065055 lb
 CG045 0.045 " 0.00040393 lb/in 18.465844424015618 lb
 CG048 0.048 " 0.00043541 lb/in 19.904967000868066 lb
 CG050 0.05 " 0.00047042 lb/in 21.50546513986439 lb
 CG052 0.052 " 0.00049667 lb/in 22.705495878186408 lb
 CG056 0.056 " 0.00059075 lb/in 27.006406044332493 lb
 CG065 0.065 " 0.00089364 lb/in 40.85316072358407 lb
 Phosphor Bronze - Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 PB020 0.02 " 8.106e-05 lb/in 3.7056949199383693 lb
 PB021 0.021 " 8.944e-05 lb/in 4.088790447067453 lb
 PB022 0.022 " 9.876e-05 lb/in 4.514858503492639 lb
 PB023 0.023 " 0.00010801 lb/in 4.937726477948967 lb
 PB024 0.024 " 0.00011682 lb/in 5.340479651458182 lb
 PB025 0.025 " 0.00012686 lb/in 5.799462836705915 lb
 PB026 0.026 " 0.0001364 lb/in 6.235588293604659 lb
 PB027 0.027 " 0.00014834 lb/in 6.781430846578558 lb
 PB029 0.029 " 0.00017381 lb/in 7.94580352867614 lb
 PB030 0.03 " 0.0001866 lb/in 8.530504219843321 lb
 PB032 0.032 " 0.00021018 lb/in 9.608474688781724 lb
 PB034 0.034 " 0.00023887 lb/in 10.920051141446809 lb
 PB035 0.035 " 0.00025365 lb/in 11.595725591442974 lb
 PB036 0.036 " 0.0002683 lb/in 12.2654570320684 lb
 PB039 0.039 " 0.00031125 lb/in 14.228935897246698 lb
 PB042 0.042 " 0.00036722 lb/in 16.787630008632718 lb
 PB045 0.045 " 0.00041751 lb/in 19.0866603259742 lb
 PB047 0.047 " 0.00045289 lb/in 20.704073183948783 lb
 PB049 0.049 " 0.00049151 lb/in 22.469604121624826 lb
 PB052 0.052 " 0.00055223 lb/in 25.24544665232625 lb
 PB053 0.053 " 0.00056962 lb/in 26.040438444304144 lb
 PB056D 0.056 " 0.00063477 lb/in 29.018800448177632 lb
 PB059 0.059 " 0.00070535 lb/in 32.24539738192116 lb
 PB060 0.06 " 0.00073039 lb/in 33.390112417638605 lb
 PB062 0.062 " 0.00077682 lb/in 35.512681072125886 lb
 PB064 0.064 " 0.0008278 lb/in 37.843255054588965 lb
 PB066 0.066 " 0.00087718 lb/in 40.10068430633529 lb
 PB070 0.07 " 0.00096833 lb/in 44.26764818435629 lb
 Copyright Jean-Pierre "lbop" Bourgeois 2002
LA (A) 110 Hz
 2 ème corde    La (A) 2ème octave     110.0 Hz
 Strictement valable pour les cordes d'Addario  extrapolable aux autres marques
 (source: http://www.daddariostrings.com/img/Tension_chart.pdf)
 Fréquence (Hz):   110.0  (fréquence  en Hertz  de la note à vide choisie)
  Utilisation
 1) renseigner la longueur  les autres valeurs sont calculées
 2) choisir une tension en livre (lb)
 La masse linéique (Unit Weight) est indiquée en livre-masse par pouce (lb/in)
 Longueur (pouces):   25.5  (longeur  en pouce  de la corde à vide)
 Plain Steel
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)   A titre d'exemple  l'accordage classique d'une guitare 6 cordes est:
 PL007 0.007 " 1.085e-05 lb/in 0.883727445652174 lb
 PL008 0.008 " 1.418e-05 lb/in 1.154954394409938 lb  n° de corde note fréquence
 PL0085 0.085 " 1.6e-05 lb/in 1.303192546583851 lb  1.0 Mi (E)1ère octave 82.41 Hz
 PL009 0.09 " 1.794e-05 lb/in 1.4612046428571428 lb  2.0 La (A) 2ème octave 110.0 Hz
 PL0095 0.085 " 1.999e-05 lb/in 1.628176187888199 lb  3.0 Ré (D) 2ème octave 146.83 Hz
 PL010 0.01 " 2.215e-05 lb/in 1.804107181677019 lb  4.0 Sol (G) 2ème octave 196.0 Hz
 PL0105 0.0105 " 2.44e-05 lb/in 1.9873686335403729 lb  5.0 Si (B) 3ème octave 264.94 Hz
 PL011 0.011 " 2.68e-05 lb/in 2.1828475155279503 lb  6.0 Mi (E) 3ème octave 329.63 Hz
 PL0115 0.0115 " 2.93e-05 lb/in 2.3864713509316773 lb
 PL012 0.012 " 3.19e-05 lb/in 2.598240139751553 lb
 PL013 0.013 " 3.744e-05 lb/in 3.049470559006212 lb
 PL014 0.014 " 4.3422e-05 lb/in 3.536701672360249 lb
 PL015 0.015 " 4.9842e-05 lb/in 4.0596076816770195 lb
 PL016 0.016 " 5.6713e-05 lb/in 4.6192474309006215 lb
 PL017 0.017 " 6.4023e-05 lb/in 5.214643525621118 lb
 PL018 0.018 " 7.1772e-05 lb/in 5.845795965838509 lb
 PL019 0.019 " 7.9973e-05 lb/in 6.513763595496895 lb
 PL020 0.02 " 8.8613e-05 lb/in 7.217487570652174 lb
 PL022 0.022 " 0.000107223 lb/in 8.733263401397517 lb
 PL024 0.024 " 0.000127604 lb/in 10.393286357142857 lb
 PL026 0.026 " 0.000149754 lb/in 12.197393538819874 lb
 Nickelplated Steel Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 NW017 0.017 " 5.524e-05 lb/in 4.4992722670807455 lb
 NW018 0.018 " 6.215e-05 lb/in 5.062088548136647 lb
 NW019 0.019 " 6.947e-05 lb/in 5.658299138198758 lb
 NW020 0.02 " 7.495e-05 lb/in 6.104642585403727 lb
 NW021 0.021 " 8.293e-05 lb/in 6.754609868012422 lb
 NW022 0.022 " 9.184e-05 lb/in 7.480325217391305 lb
 NW024 0.024 " 0.00010857 lb/in 8.842975923913045 lb
 NW026 0.026 " 0.00012671 lb/in 10.320470473602487 lb
 NW028 0.028 " 0.00014666 lb/in 11.945388680124223 lb
 NW030 0.03 " 0.00017236 lb/in 14.038641708074534 lb
 NW032 0.032 " 0.00019347 lb/in 15.758041374223604 lb
 NW034 0.034 " 0.0002159 lb/in 17.58495442546584 lb
 NW036 0.036 " 0.00023964 lb/in 19.51856636645963 lb
 NW038 0.038 " 0.00026471 lb/in 21.560506187888198 lb
 NW039 0.04 " 0.00027932 lb/in 22.750483881987577 lb
 NW042 0.042 " 0.00032279 lb/in 26.29109513198758 lb
 NW044 0.044 " 0.00035182 lb/in 28.655575108695654 lb
 NW046 0.046 " 0.00038216 lb/in 31.12675397515528 lb
 NW048 0.048 " 0.00041382 lb/in 33.705446226708084 lb
 NW049 0.049 " 0.00043014 lb/in 35.0347026242236 lb
 NW052 0.052 " 0.00048109 lb/in 39.184556389751556 lb
 NW054 0.054 " 0.00053838 lb/in 43.85080020186335 lb
 NW056 0.056 " 0.00057598 lb/in 46.91330268633541 lb
 NW059 0.059 " 0.00064191 lb/in 52.283270473602485 lb
 NW060 0.06 " 0.00066542 lb/in 54.198149021739134 lb
 NW062 0.062 " 0.00070697 lb/in 57.58237716614907 lb
 NW064 0.064 " 0.00074984 lb/in 61.07411869565218 lb
 NW066 0.066 " 0.00079889 lb/in 65.0692183462733 lb
 NW068 0.068 " 0.00084614 lb/in 68.91770883540373 lb
 NW070 0.07 " 0.00089304 lb/in 72.73769198757763 lb
 NW072 0.072 " 0.00094124 lb/in 76.6635595341615 lb
 NW074 0.074 " 0.00098869 lb/in 80.52833993012422 lb
 NW080 0.08 " 0.00115011 lb/in 93.67592373447205 lb
 Stainless Steel Rounwound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 XSG028 0.028 " 0.00015493 lb/in 12.618976327639754 lb
 XSG030 0.03 " 0.00018203 lb/in 14.826258703416146 lb
 XSG032 0.032 " 0.00020398 lb/in 16.61407597826087 lb
 XSG034 0.034 " 0.00022729 lb/in 18.512664619565218 lb
 XSG036 0.036 " 0.00025198 lb/in 20.523653618012425 lb
 XSG038 0.038 " 0.00027804 lb/in 22.646228478260873 lb
 XSG040 0.04 " 0.00031044 lb/in 25.285193385093166 lb
 XSG042 0.042 " 0.00033924 lb/in 27.630939968944098 lb
 XSG046 0.046 " 0.00040096 lb/in 32.658005217391306 lb
 XSG048 0.048 " 0.00043387 lb/in 35.33850938664596 lb
 XSG050 0.05 " 0.00046816 lb/in 38.13141391304349 lb
 XSG052 0.052 " 0.00050382 lb/in 41.03590430124223 lb
 XSG054 0.054 " 0.00056388 lb/in 45.92776332298137 lb
 XSG056 0.056 " 0.00060297 lb/in 49.11162561335405 lb
 XSG070 0.07 " 0.00092592 lb/in 75.41575267080748 lb
 Stainless Steel Half Round
 Item# Tirant (pouces)  Unit Weight (lb/in)  Tension (livres)
 HRG022 0.022 " 0.00011271 lb/in 9.180176995341617 lb
 HRG024 0.024 " 0.00012857 lb/in 10.471966607142859 lb
 HRG026 0.026 " 0.0001475 lb/in 12.013806288819877 lb
 HRG030 0.03 " 0.0001897 lb/in 15.450976630434784 lb
 HRG032 0.032 " 0.000211 lb/in 17.185851708074537 lb
 HRG036 0.036 " 0.0002565 lb/in 20.891805512422362 lb
 HRG039 0.039 " 0.000297 lb/in 24.19051164596273 lb
 HRG042 0.042 " 0.000334 lb/in 27.20414440993789 lb
 HRG046 0.046 " 0.0003981 lb/in 32.42505954968944 lb
 HRG052 0.052 " 0.000495 lb/in 40.31751940993789 lb
 HRG056 0.056 " 0.000567 lb/in 46.18188586956522 lb
 Chromes - Stainless Steel Flat Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 CG020 0.02 " 7.812e-05 lb/in 6.362837608695653 lb
 CG022 0.022 " 9.784e-05 lb/in 7.96902242236025 lb
 CG024 0.022 " 0.00011601 lb/in 9.448960458074534 lb
 CG026 0.022 " 0.00013574 lb/in 11.055959767080745 lb
 CG028 0.022 " 0.00014683 lb/in 11.959235100931677 lb
 CG030 0.022 " 0.00016958 lb/in 13.812212003105591 lb
 CG032 0.022 " 0.00019233 lb/in 15.665188905279503 lb
 CG035 0.035 " 0.00024197 lb/in 19.7083437810559 lb
 CG038 0.036 " 0.0002652 lb/in 21.60041645962733 lb
 CG040 0.04 " 0.00031676 lb/in 25.79995444099379 lb
 CG042 0.042 " 0.00034377 lb/in 27.999906358695654 lb
 CG045 0.045 " 0.00040393 lb/in 32.89991033385093 lb
 CG048 0.048 " 0.00043541 lb/in 35.46394166925466 lb
 CG050 0.05 " 0.00047042 lb/in 38.31548986024845 lb
 CG052 0.052 " 0.00049667 lb/in 40.45354013198758 lb
 CG056 0.056 " 0.00059075 lb/in 48.116312305900614 lb
 CG065 0.065 " 0.00089364 lb/in 72.78656170807454 lb
 Phosphor Bronze - Round Wound
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)
 PB020 0.02 " 8.106e-05 lb/in 6.602299239130436 lb
 PB021 0.021 " 8.944e-05 lb/in 7.284846335403727 lb
 PB022 0.022 " 9.876e-05 lb/in 8.04395599378882 lb
 PB023 0.023 " 0.00010801 lb/in 8.797364184782609 lb
 PB024 0.024 " 0.00011682 lb/in 9.51493458074534 lb
 PB025 0.025 " 0.00012686 lb/in 10.332687903726708 lb
 PB026 0.026 " 0.0001364 lb/in 11.10971645962733 lb
 PB027 0.027 " 0.00014834 lb/in 12.082223897515528 lb
 PB029 0.029 " 0.00017381 lb/in 14.156743532608699 lb
 PB030 0.03 " 0.0001866 lb/in 15.198483074534165 lb
 PB032 0.032 " 0.00021018 lb/in 17.11906309006211 lb
 PB034 0.034 " 0.00023887 lb/in 19.45585022515528 lb
 PB035 0.035 " 0.00025365 lb/in 20.659674340062114 lb
 PB036 0.036 " 0.0002683 lb/in 21.852910015527957 lb
 PB039 0.039 " 0.00031125 lb/in 25.351167507763975 lb
 PB042 0.042 " 0.00036722 lb/in 29.909897934782613 lb
 PB045 0.045 " 0.00041751 lb/in 34.00599500776397 lb
 PB047 0.047 " 0.00045289 lb/in 36.88767952639751 lb
 PB049 0.049 " 0.00049151 lb/in 40.033260535714284 lb
 PB052 0.052 " 0.00055223 lb/in 44.97887625 lb
 PB053 0.053 " 0.00056962 lb/in 46.395283649068325 lb
 PB056D 0.056 " 0.00063477 lb/in 51.70172079968944 lb
 PB059 0.059 " 0.00070535 lb/in 57.45042892080746 lb
 PB060 0.06 " 0.00073039 lb/in 59.489925256211194 lb
 PB062 0.062 " 0.00077682 lb/in 63.271627127329204 lb
 PB064 0.064 " 0.0008278 lb/in 67.42392437888199 lb
 PB066 0.066 " 0.00087718 lb/in 71.4459023757764 lb
 PB070 0.07 " 0.00096833 lb/in 78.87002741459627 lb
 Copyright Jean-Pierre "lbop" Bourgeois 2002
Ré (D) 146 83 Hz
 3 ème corde    Ré (D) 2ème octave     146.83 Hz
 Strictement valable pour les cordes d'Addario  extrapolable aux autres marques
 (source: http://www.daddariostrings.com/img/Tension_chart.pdf)
 Fréquence (Hz):   146.83  (fréquence  en Hertz  de la note à vide choisie)
  Utilisation
 1) renseigner la longueur  les autres valeurs sont calculées
 2) choisir une tension en livre (lb)
 La masse linéique (Unit Weight) est indiquée en livre-masse par pouce (lb/in)
 Longueur (pouces):   25.5  (longeur  en pouce  de la corde à vide)
 Plain Steel
 Item# Tirant (pouce)  Unit Weight (lb/in)  Tension (livre)   A titre d'exemple  l'accordage classique d'une guitare 6 cordes est:
 PL007 0.007 " 1.085e-05 lb/in 1.5745721665361414 lb
 PL008 0.008 " 1.418e-05 lb/in 2.0578279558970034 lb  n° de corde note fréquence
 PL0085 0.085 " 1.6e-05 lb/in 2.321949738670808 lb  1.0 Mi (E)1ère octave 82.41 Hz
 PL009 0.09 " 1.794e-05 lb/in 2.603486144484643 lb  2.0 La (A) 2ème octave 110.0 Hz
 PL0095 0.085 " 1.999e-05 lb/in 2.9009859547518406 lb  3.0 Ré (D) 2ème octave 146.83 Hz
 PL010 0.01 " 2.215e-05 lb/in 3.2144491694724002 lb  4.0 Sol (G) 2ème octave 196.0 Hz
 PL0105 0.0105 " 2.44e-05 lb/in 3.5409733514729824 lb  5.0 Si (B) 3ème octave 264.94 Hz
 PL011 0.011 " 2.68e-05 lb/in 3.889265812273603 lb  6.0 Mi (E) 3ème octave 329.63 Hz
 PL0115 0.0115 " 2.93e-05 lb/in 4.252070458940916 lb
 PL012 0.012 " 3.19e-05 lb/in 4.629387291474925 lb
 PL013 0.013 " 3.744e-05 lb/in 5.433362388489691 lb
 PL014 0.014 " 4.3422e-05 lb/in 6.301481347035239 lb
 PL015 0.015 " 4.9842e-05 lb/in 7.233163679676901 lb
UniversalStringsGauges (XLS) - Fichier XLS

UniversalStringsGauges (XLS)

Aperçu texte

Sur le même sujet

Partager le fichier

Lien court

Code HTML

Code BB

Lien permanent
